Mobiles Compressed air flushing system for cleaning and disinfecting pipework
HEAWAT mobile
Item no.
N80240805
HEAWAT mobile
Item no.
N80240805
Further information and Product information
- Integrated water inlet filter
- Pressure regulator for compressed air and water
- Backflow protection for compressed air and water
| Specification | Value |
|---|---|
Hose/pipe size | up to 1¼" |
Max. Compressed air pressure | 6 bar |
Compressed air connection | Plug nipple NW 7.2 mm |
Water connections | GEKA coupling ½" |
Housing | Sheet steel, powder-coated (RAL 7035) with 3 mm double-bit fasteners |
Control system | Flush - Off - Pulse (pulse-pause adjustable) |
Degree of protection | IP65 |
Supply voltage | 230 V AC, 50 Hz |
Power consumption | approx. 150 W |
Electrical connection | 3 m mains cable with Schuko plug CEE 7/7 |
Dimensions (L×W×H) | 47 × 21.5 × 58 cm |
Weight (empty) | 19.3 kg |
Device options | Dosing device for precise mixing of disinfectants or cleaning agents |
Trolley for easy transport and attachment of the dosing unit |
Miscellaneous Areas of application.
Chicken coops
Drinking water pipes in private households
Agricultural water pipes
Food processing companies
Get in touch with us for your individual project!
The PfalzTec HEAWAT mobile is a compact and robust flushing system for the effective cleaning and disinfection of pipework in accordance with DVGW W551. Compressed air is pulsed into the water pipe via an adjustable pulse-pause ratio, optionally simultaneously with disinfectants or cleaning agents. The integrated pressure control for air and water, backflow protection and a water inlet filter ensure maximum safety and reliability. The device is suitable for hose and pipe sizes up to 1¼“ and can be easily transported thanks to the optional trolley.
